Analysts can make simulation-driven design possible with geometry control, reduce delays between design teams and analysts, and quickly understand how design changes affect outcomes. SpaceClaim eliminates geometry bottlenecks, allowing analysts to concentrate on their simulations, whether de-featuring CAD models, removing fluid domains, or simplifying a model for beam and shell components. Reduce Prep Time for SimulationĪnsys SpaceClaim 2021 provides analysts with tools to speed up simulation training for geometry. Ansys SpaceClaim 2021 is suitable for engineers who do not have time for heavy CAD devices but want to get 3D responses quickly and need to do so. You can de-feature and simplify geometry with digital, easy-to-learn instruments when working with existing CAD models. Without the complexities associated with conventional CAD systems, Ansys SpaceClaim 2021‘s unique user interface, modeling technology, and flexible toolset help you build and change imported geometry.

If you need to find the Ansys SpaceClaim API, then it is located in your Ansys SpaceClaim installation folder (somewhere along the lines of “C:\Program Files\ANSYS Inc\v212\scdm”).Description ANSYS SpaceClaim 2021 Overview Included with that course are several workshops that go over various scripting aspects for selections, operations, groups, etc.

If you have access to the ANSYS Learning Hub then I recommend taking the Ansys SpaceClaim Scripting course located here: Structures | Customization – Scripting in Ansys SpaceClaim (). Note that standard parametric CAD caveats apply with Block Recording i.e.: you have to be mindful of constraints and dependencies of upstream blocks as it is possible to invalidate operations by making changes that effectively remove a later block’s geometry in an earlier step. This is denoted by the “P” button next to applicable items within that block. Just like with script recording, you can promote certain entities within each block as Parameters for use in design studies.
